Designed by Steve Shumate
If you download plans and build the F-22, please consider sending the designer a donation for all of his hard work and inspiration!! PayPal welcomed!
PayPal | jetset44@gmail.com
Suggested Donation: $10.00
Note this design is quite a bit more complex than my other park jet designs, due mostly to the complex geometry of the real F/A-22. It requires a LOT of heat forming foam as well as making a lot of bevel cuts and aligning parts at odd angles. If you haven’t built a park jet before, this is NOT the model to start with! It will be a challenging build. But if you’ve built other park jets it shouldn’t be too difficult.
Wing area: 248 sq in | Span: 26.0" | Length: 36.3" | Weight RTF: 16 to 18 oz (estimate) | Wing loading: 10.5 oz/ft2 | Current: 15 amps | Watts: 150 watts | Power loading: 140 to 150 watts/lb | Flight controls: Stabilator, flaperons, rudder (optional), thrust vectoring (optional)
Links below are affiliate links — if you buy through them, Parkjets earns a small commission at no extra cost to you.
Motor: 2212 2200KV Brushless Outrunner → Amazon | Banggood (budget)
ESC: 30A brushless ESC → Amazon | Banggood (budget)
Propeller: APC 7x4 (aerobatics) or APC 6x5.5 (speed) → Amazon | Banggod (budget)
Battery: 3S 1300mAh LiPo → Amazon | Banggood (budget)
Servos: 9g micro servos x2 → Amazon | Banggood (budget)
